Day/Night Vision Cameras
Crystal 42 Nova
Crystal 42 Nova
Crystal is our compact CMOS imaging core with a monochrome or colour CMOS sensor. Sharp, crisp and colour-calibrated image over HD-SDI, PAL, CameraLink or USB3 output. Easy to integrate and to interface with and fully designed and built in Europe. Versatile, economical and readily available. Based on the compact and FPGA powered ARGON platform.
Useful for situational awareness systems and rugged enough for target acquisition systems. Contact us for retrofits if your current analogue camera module was declared obsolete.
Key features
- PAL/NTSC analog output
- High sensitive CMOS from Sony
- Sturdy housing, made to retrofit if needed
Technical Specifications
Day/Night Vision Cameras Crystal 42 Nova
01
System Basics
- Sensor IMX265LQR
- Resolution 720 x 480 (NTSC) or 768 x 576 (PAL)
- Frame Rate 30 or 25 fps
- Aspect Ratio 4:3
- Pixel Pitch 3.45 x 3.45 µm
- Spectral Color visual
- Exposure mode Global shutter
- White balance Automatic or manual
- Analog Sensor Gain 0 to 40dB
- Max S/N >45dB
- Latency 2-3 frames
02
Input / Output
- Output PAL or NTSC
- External trigger input Not present
- External sync input Not present
- UART communication LVTTL UART
- LVDS / CameraLink Not present
- Serial Digital Interface (SDI) Not present
- Composite Video (CBVS) Present
- S-video (Y/C) Present
- Individual RGB channels (analog or digital) Not present
- Genlock capability Unknown
03
Features
- Digital Zoom Not present
- Gamma Correction BT.709
- ShadowBoost Present
- Sharpening Present
- Histogram stretching / normalization Present
- Symbology insertion OSD Not present
- Color calibration Present
- Vignetting correction Present
- Latency 2-3 frames
04
Physical Dimensions
- External dimension 44 x 42 x 54mm w/o lens
- Weight 127g
- Operating temperature range -30°C to +75°C
- Storage temperature range -40°C to +85°C
- Performance guarantee temperature -10°C to +60°C
05
Power
- Power supply 6-16Vdc
- Power consumption < 3.0 Watt
