Thermal Cameras
Full featured SWIR core
Ruby 6-15 SWIR
Ruby is a compact ARGON based core with a short-wave infrared detector of 640 x 512 pixels. All image calibration and dynamic range control is performed by the core. Output is either CameraLink or USB3.
A SWIR sensor works in a spectral region where the atmosphere is almost fully transparent. And, as such, it can provide a contrast-rich image from scenery of > 10km away. Perfect for long range observation at sea. The Ruby also works in the spectral range where laser designators are active, and it can thus be used to construct a laser warning system.
Key features
- Lynred SNAKE SW TECLESS sensor
- Frame rate of 50 - 180 fps
- Global Shutter as Exposure mode
Technical Specifications
Thermal Cameras Ruby 6-15 SWIR
01
System Basics
- Sensor Lynred SNAKE SW TECLESS
- Resolution 640 x 512
- Frame Rate 50 - 180 fps
- Aspect Ratio 5:4
- Pixel Pitch 15 μm
- Spectral SWIR (1.0 - 1.6 µm)
- Exposure mode Global Shutter
- Detector sensitivity QE > 70%
- Latency < 1 frame
02
Input / Output
- Output CameraLink, USB3
- External trigger input Present
- External sync input 1.8 – 2.5V
- UART communication Present
- Communication LVTTL UART
- LVDS / CameraLink Present
- Serial Digital Interface (SDI) Not present
03
Features
- Histogram stretching / normalization Vignetting correction
- Vignetting correction Not present
- FPN correction Calibrated, shutterless
04
Physical Dimensions
- External dimension 35 x 35 x 21mm w/o lens
- Weight 52g (w/o lens mount 40g)
- Operating temperature range -20°C to + 60°C
- Storage temperature range -20°C to + 60°C
- Performance guarantee temperature -20°C to + 60°C
05
Power
- Power supply 5Vdc
- Power consumption < 2.0 Watt
